See Price & Buy at The Restaurant WarehouseThe Atosa ATMG-48-LP is a 48" wide gas griddle with a 3/4" thick polished steel plate and manual controls for each 12" section. It runs on propane with 120,000 BTU in total.
At a Glance
- Size: 48" W x 28-3/5" D x 15-1/5" H (from the Atosa drawing)
- Work area: 47-9/10" x 19-9/10"
- Plate: 3/4" thick polished steel
- Gas: propane, 4 burners, 120,000 BTU total
- Controls: independent manual control for each 12" section
- Certifications: cETLus, ETL-Sanitation
- Warranty: 1 year parts and labor (US only)
Most units ship within one business day from our warehouse with free freight and free lift gate to Seattle restaurants and the lower 48.
A 48 Inch Propane Griddle
This 48 inch propane griddle has a 3/4" thick polished steel plate and four 30,000 BTU burners. Each 12" section has its own manual control.
Is the ATMG-48-LP the Right Manual Griddle for Your Line?
This is the propane ATMG at 48": four manually controlled 12" zones, 30,000 BTU per burner (120,000 BTU total), and a 3/4" polished steel plate with about 953 sq in of cooking space (47-9/10" x 19-9/10"). Plan for 294 lb on the counter and 414 lb on delivery.
The regulator is set at 10" W.C. for propane, on a 3/4" NPT rear connection. The natural gas ATMG-48-NG has the same size and BTU with a 4" W.C. regulator.
For propane, the other Atosa choice at 48" is the thermostatic ATTG-48-LP: a 1" plate, 25,000 BTU burners (100,000 BTU total) and a thermostat for each zone, at a higher price. Pick the ATMG-48-LP if your cooks prefer to set the heat by hand and you want the most burner output. Short on space: the ATMG-36-LP is 36" wide. Pair it with the ATRC-48-LP propane charbroiler: the same 48" width and 15-1/5" height, at 27-3/5" deep.
Good For
- Large propane kitchens: 120,000 BTU across four manual zones
- Camps and banquet halls: a 48" flat top without a gas main
- Catering on propane: about 953 sq in of cooking space
- Big breakfast menus: four foods at four heat settings
Built for Daily Commercial Use
- Stainless steel exterior and interior
- Stainless steel grease drawer
- Heavy duty 3/4" thick polished steel griddle plate
- 30,000 BTU burner for each 12" section, with standby pilots
- Independent manual control for each 12" section
- Stainless steel legs standard
- 3/4" NPT rear gas connection and regulator standard
Pick the Right Size
| Model | Gas | Width | Burners | Total BTU |
|---|---|---|---|---|
| ATMG-24-NG | Natural gas | 24" | 2 | 60,000 |
| ATMG-24-LP | Propane | 24" | 2 | 60,000 |
| ATMG-36-NG | Natural gas | 36" | 3 | 90,000 |
| ATMG-36-LP | Propane | 36" | 3 | 90,000 |
| ATMG-48-NG | Natural gas | 48" | 4 | 120,000 |
| ATMG-48-LP (this model) | Propane | 48" | 4 | 120,000 |
Need natural gas? See the Atosa ATMG-48-NG. Want thermostatic controls? See the Atosa ATTG-48-LP.
Shop all commercial griddles, including propane and manual models.
Buy the Atosa ATMG-48-LP in Seattle
Encore Seattle sells the Atosa ATMG-48-LP new, not used, with the full manufacturer warranty. If you are pricing a commercial griddle in Seattle, it ships with free freight to Seattle restaurants on orders over $500, and we offer 1-3 day delivery from 12 distribution centers. We deliver to kitchens in Georgetown, Greenwood, Pike Place Market and Beacon Hill, and to restaurants across the lower 48.
Compare more options in our Commercial Griddles Seattle collection, or call or text +1 (206) 419-5801 with questions.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Countertop manual gas griddle |
| Gas type | Propane (LP) |
| Griddle plate | 3/4" thick polished steel |
| Work area | 47-9/10" x 19-9/10" |
| Burners | 4, 30,000 BTU each |
| Total BTU | 120,000 |
| Controls | Independent manual, one per 12" section |
| Gas pressure (regulator) | 10" W.C. |
| Gas connection | 3/4" NPT, rear, with regulator |
| Grease drawer | Stainless steel |
| Legs | Stainless steel |
| Construction | Stainless steel exterior and interior |
| Exterior dimensions | 48" W x 28-3/5" D x 15-1/5" H (from the Atosa drawing) |
| Net weight | 294 lb |
| Shipping weight | 414 lb |
| Warranty | 1 year parts and labor (US only) |
| Certifications | cETLus, ETL-Sanitation; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b |
Before You Order
- This is the propane model. Order the ATMG-48-NG for natural gas.
- Gas: 3/4" NPT rear connection with a regulator. Atosa lists the regulator at 10" W.C. for propane.
- Check your counter: the ATMG-48-LP is 48" wide, 28-3/5" deep and 15-1/5" tall, per the Atosa drawing. It weighs 294 lb, so use a counter or stand rated for that weight.
Atosa ATMG-48-LP FAQ
What size is the Atosa ATMG-48-LP?
48" wide, 28-3/5" deep and 15-1/5" tall, per the Atosa drawing, with a 47-9/10" x 19-9/10" work area. It weighs 294 lb, or 414 lb shipped.
How many BTU is the ATMG-48-LP?
120,000 BTU total from four 30,000 BTU burners, on propane. That is more than the 100,000 BTU thermostatic ATTG-48-LP.
How thick is the ATMG-48-LP griddle plate?
3/4" thick polished steel. The thermostatic ATTG-48-LP has a 1" plate.
Does the ATMG-48-LP have thermostatic controls?
No. Each of the four 12" sections has its own manual valve. For thermostats, see the ATTG-48-LP.
What gas connection does the ATMG-48-LP need?
A 3/4" NPT rear connection with a regulator set at 10" W.C. for propane. For natural gas, order the ATMG-48-NG.
What certifications does the ATMG-48-LP have?
cETLus, ETL-Sanitation; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b.
What warranty comes with the ATMG-48-LP?
1 year parts and labor (US only) on the ATMG-48-LP.
Can I use the ATMG-48-LP in a food truck?
Many food trucks run propane griddles, but check your local fire code first. The ATMG-48-LP is 48" wide, 28-3/5" deep and 294 lb, with 120,000 BTU, and it should be installed by a licensed technician.
Where can I buy the Atosa ATMG-48-LP in Seattle?
Right here at Encore Seattle. The ATMG-48-LP is new and ships to your restaurant with free freight on orders over $500.
How fast can I get the ATMG-48-LP in Seattle?
We offer 1-3 day delivery from 12 distribution centers. Call or text +1 (206) 419-5801 to check timing for your address.
