Atosa ATRC-36-NG 36-Inch Countertop Radiant Charbroiler, Natural Gas, 105,000 BTU
See current pricing, availability and checkout for this item at The Restaurant Warehouse, our main store.
See Price & Buy at The Restaurant WarehouseThe Atosa ATRC-36-NG is a 36" wide countertop radiant charbroiler with 3 burners and 105,000 BTU on natural gas. It has reversible cast iron grates and a manual control every 12".
At a Glance
- Size: 36" W x 27-3/5" D x 15-1/5" H (from the Atosa drawing)
- Work area: 35-7/10" x 20-1/5"
- Gas: natural gas, 3 burners, 105,000 BTU total
- Grates: heavy-duty reversible cast iron, adjustable multi-level
- Controls: independent manual control every 12"
- Certifications: cETLus, ETL-Sanitation
- Warranty: 1 year parts and labor (US only)
Most units ship within one business day from our warehouse with free freight and free lift gate to Seattle restaurants and the lower 48.
A 36" Commercial Gas Grill with Radiants
This commercial gas grill is a 36" radiant charbroiler with three 35,000 BTU burners. It runs on natural gas with 105,000 BTU in total and has a manual control for each 12" section.
Is the ATRC-36-NG the Right Charbroiler for Your Line?
The ATRC-36-NG is 36" wide with three 12" zones, each on its own 35,000 BTU stainless steel burner and manual control, for 105,000 BTU on natural gas. Radiants sit over the burners and spread the heat under 35-7/10" x 20-1/5" of reversible cast iron grate, about 721 sq in. It weighs 158.7 lb, or 205 lb shipped.
Radiant or lava rock? The lava rock ATCB-36 has the same size, burners and BTU but cooks over a bed of lava briquettes, which some cooks prefer for flavor. It weighs 32.2 lb more, and the rock has to be spread and replaced over time. With radiants, there is no rock to manage.
Set up for natural gas with a 4" W.C. regulator. The ATRC-36-LP is the same charbroiler for propane. Need another zone? The ATRC-48-NG is 48" wide. Short on space? The ATRC-24-NG is 24" wide. Building a line? The ATTG-36-NG thermostatic and ATMG-36-NG manual griddles are the same 36" width and 15-1/5" height, 1" deeper at 28-3/5".
Good For
- Burger joints: flame-grilled burgers across three 35,000 BTU zones
- Fast casual restaurants: chicken, steak and vegetables for bowls and wraps
- Taquerias: carne asada on about 721 sq in of grate
- Busy lines: radiants with no rock to manage
Built for Daily Commercial Use
- Stainless steel exterior and interior
- 35,000 BTU stainless steel burners with standby pilots
- Independent manual controls every 12"
- Heavy-duty, reversible cast iron grates
- Top grates adjust to more than one level
- Adjustable stainless steel legs
- 3/4" NPT rear gas connection and regulator standard
Pick the Right Size
| Model | Gas | Width | Burners | Total BTU |
|---|---|---|---|---|
| ATRC-24-NG | Natural gas | 24" | 2 | 70,000 |
| ATRC-24-LP | Propane | 24" | 2 | 70,000 |
| ATRC-36-NG (this model) | Natural gas | 36" | 3 | 105,000 |
| ATRC-36-LP | Propane | 36" | 3 | 105,000 |
| ATRC-48-NG | Natural gas | 48" | 4 | 140,000 |
| ATRC-48-LP | Propane | 48" | 4 | 140,000 |
Need propane? See the Atosa ATRC-36-LP. Prefer lava rock? See the Atosa ATCB-36.
Shop all commercial charbroilers, including radiant and natural gas models.
Buy the Atosa ATRC-36-NG in Seattle
Encore Seattle sells the Atosa ATRC-36-NG new, not used, with the full manufacturer warranty. If you are pricing a commercial charbroiler in Seattle, it ships with free freight to Seattle restaurants on orders over $500, and we offer 1-3 day delivery from 12 distribution centers. We deliver to kitchens in Capitol Hill, Ballard, Fremont and South Lake Union, and to restaurants across the lower 48.
Compare more options in our Commercial Charbroilers Seattle collection, or call or text +1 (206) 419-5801 with questions.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Countertop radiant charbroiler |
| Gas type | Natural gas |
| Burners | 3, stainless steel, 35,000 BTU each, standby pilots |
| Total BTU | 105,000 |
| Controls | Independent manual, every 12" |
| Work area | 35-7/10" x 20-1/5" |
| Grates | Heavy-duty reversible cast iron, adjustable multi-level |
| Gas pressure (regulator) | 4" W.C. |
| Gas connection | 3/4" NPT, rear, with regulator |
| Legs | Adjustable stainless steel |
| Construction | Stainless steel exterior and interior |
| Exterior dimensions | 36" W x 27-3/5" D x 15-1/5" H (from the Atosa drawing) |
| Net weight | 158.7 lb |
| Shipping weight | 205 lb |
| Warranty | 1 year parts and labor (US only) |
| Certifications | cETLus, ETL-Sanitation; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b |
Before You Order
- This is the natural gas model. Order the ATRC-36-LP for propane.
- Gas: 3/4" NPT rear connection with a regulator. Atosa lists the regulator at 4" W.C. for natural gas.
- Check your counter: the ATRC-36-NG is 36" wide, 27-3/5" deep and 15-1/5" tall, per the Atosa drawing. It weighs 158.7 lb, so use a counter or stand rated for that weight.
Atosa ATRC-36-NG FAQ
What size is the Atosa ATRC-36-NG?
36" wide, 27-3/5" deep and 15-1/5" tall, per the Atosa drawing, with a 35-7/10" x 20-1/5" work area. It weighs 158.7 lb, 32.2 lb less than the lava rock ATCB-36.
How many BTU is the ATRC-36-NG?
105,000 BTU total from three 35,000 BTU burners on natural gas. The propane ATRC-36-LP has the same rating.
What kind of grates does the ATRC-36-NG have?
Heavy-duty reversible cast iron grates that adjust to more than one level, across a 35-7/10" x 20-1/5" cooking area.
How are the ATRC-36-NG burners controlled?
Each of the three 12" sections has its own manual control and standby pilot.
What gas connection does the ATRC-36-NG need?
A 3/4" NPT rear connection with a regulator set at 4" W.C. for natural gas. For propane, order the ATRC-36-LP.
What certifications does the ATRC-36-NG have?
cETLus, ETL-Sanitation; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b.
What warranty comes with the ATRC-36-NG?
1 year parts and labor (US only) on the ATRC-36-NG.
Does the ATRC-36-NG use lava rock?
No. The ATRC-36-NG uses radiants over the burners, so there is no lava rock to spread or replace. For lava rock at the same 36" width and 105,000 BTU, see the ATCB-36, which comes with lava briquettes and weighs 32.2 lb more.
Where can I buy the Atosa ATRC-36-NG in Seattle?
Right here at Encore Seattle. The ATRC-36-NG is new and ships to your restaurant with free freight on orders over $500.
How fast can I get the ATRC-36-NG in Seattle?
We offer 1-3 day delivery from 12 distribution centers. Call or text +1 (206) 419-5801 to check timing for your address.
