Atosa ATSB-36 36-Inch Infrared Salamander Broiler, Range Mount, 43,000 BTU
See current pricing, availability and checkout for this item at The Restaurant Warehouse, our main store.
See Price & Buy at The Restaurant WarehouseThe Atosa ATSB-36 is a 36" infrared salamander broiler with two 21,500 BTU ceramic infrared burners (43,000 BTU). Each side has its own control, and it ships with a mount kit for an Atosa 36" range.
At a Glance
- Size: 36" W x 18" D x 17-1/3" H
- Burners: two (2) 21,500 BTU ceramic infrared burners with standby pilots, 43,000 BTU total
- Controls: dual valves for independent left and right sides
- Preheat: 1 minute (Atosa spec)
- Rack: removable chrome broiler rack, 4 positions
- Mounting: range mount kit included (Atosa 36" ranges only); wall mount kit optional
- Gas: natural gas (5" W.C.) or propane (10" W.C.) per the Atosa sheet
- Certifications: cETLus, ETL-Sanitation
- Warranty: 1 year parts and labor (US only)
Most units ship within one business day from our warehouse with free freight and free lift gate to Seattle restaurants and the lower 48.
A 36" Commercial Salamander Broiler
This commercial salamander broiler has two 21,500 BTU ceramic infrared burners with 43,000 BTU in total. Atosa lists a 1 minute preheat, and the chrome rack moves to 4 positions. It ships with a mount kit for an Atosa 36" range.
Is the ATSB-36 the Right Overhead Broiler for Your Line?
The ATSB-36 is the salamander of the pair. It has the same 36" frame and the same two 21,500 BTU ceramic infrared burners as the ATCM-36 cheese melter, but adds a chrome broiler rack with 4 positions and a 1 minute preheat on Atosa's spec sheet. Moving the rack up or down lets you choose how close the food sits to the burners, from a hard sear on a steak to a gentle brown on a gratin.
It is also the heavier unit: 143 lb (169 lb shipped), 48 lb more than the ATCM-36. That matters most for a wall mount, since Atosa's installation overview says the wall must be able to hold the unit's weight. The included range mount kit fits Atosa 36" ranges, such as the AGR-36G griddle range or the AGR-4B36GR. Confirm the fit with us if you are not sure about your range.
Each side runs on its own valve, so you can finish plates on the left and keep the right side off between rushes. If you only melt cheese and brown toppings, the lighter ATCM-36 has the same BTU at 95 lb.
Good For
- Steakhouses: searing and finishing steaks and chops close to the burners
- Fine dining and bistros: crème brûlée, gratins and plate finishing
- Seafood restaurants: broiling fish and finishing oysters with the rack set lower
- Busy lines: a 1 minute preheat (Atosa spec) and independent left and right sides
Built for Daily Commercial Use
- Stainless steel exterior and interior
- Dual valve controls for independent left and right side operation
- Two (2) 21,500 BTU high efficiency ceramic infrared burners with standby pilots, 43,000 BTU total
- 1 minute preheat time (Atosa spec)
- 4 position rack adjustment
- One (1) removable chrome broiler rack
- Removable crumb/grease tray
- Range mount kit ships with the unit (fits Atosa 36" ranges only)
- Optional wall mount kit 21208001048
Salamander or Cheese Melter?
| Model | Type | Rack | Net weight |
|---|---|---|---|
| ATSB-36 (this model) | Salamander broiler | Chrome, 4 positions | 143 lb |
| ATCM-36 | Cheese melter | Removable | 95 lb |
Need a lighter unit? See the Atosa ATCM-36.
Shop all commercial charbroilers, including salamander broilers and cheese melters.
Buy the Atosa ATSB-36 in Seattle
Encore Seattle sells the Atosa ATSB-36 new, not used, with the full manufacturer warranty. If you are pricing a commercial range in Seattle, it ships with free freight to Seattle restaurants on orders over $500, and we offer 1-3 day delivery from 12 distribution centers. We deliver to kitchens in Rainier Valley, Eastlake, Phinney Ridge and SoDo, and to restaurants across the lower 48.
Compare more options in our Salamanders and Cheese Melters Seattle collection, or call or text +1 (206) 419-5801 with questions.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Infrared salamander broiler, range mount |
| Burners | 2 ceramic infrared, 21,500 BTU each, standby pilots |
| Total BTU | 43,000 |
| Controls | Dual valves, independent left and right |
| Preheat time | 1 minute (Atosa spec) |
| Rack | Removable chrome broiler rack, 4 positions |
| Grease tray | Removable crumb/grease tray |
| Gas pressure (regulator) | 5" W.C. natural gas, 10" W.C. propane |
| Mounting | Range mount kit included (Atosa 36" ranges only); wall mount kit 21208001048 optional |
| Construction | Stainless steel exterior and interior |
| Exterior dimensions | 36" W x 18" D x 17-1/3" H |
| Net weight | 143 lb |
| Shipping weight | 169 lb |
| Warranty | 1 year parts and labor (US only) |
| Certifications | cETLus, ETL-Sanitation; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b |
Before You Order
- Gas: Atosa lists 5" W.C. for natural gas and 10" W.C. for propane.
- The range mount kit fits Atosa 36" ranges only. The optional wall mount kit 21208001048 is also available.
- Check your space: the ATSB-36 is 36" wide, 18" deep and 17-1/3" tall. It weighs 143 lb.
- Atosa's installation overview says the wall must be flat, solid and able to hold the unit's weight, and to follow local building and fire codes.
- For a wall mount, the wall must hold the ATSB-36's 143 lb.
Atosa ATSB-36 FAQ
What size is the Atosa ATSB-36?
36" wide, 18" deep and 17-1/3" tall, the same frame as the ATCM-36. The ATSB-36 weighs 143 lb, or 169 lb shipped, which is 48 lb more than the ATCM-36.
How many BTU is the ATSB-36?
43,000 BTU from two 21,500 BTU ceramic infrared burners, the same rating as the ATCM-36. What sets the salamander apart is the 4 position chrome rack and the 1 minute preheat.
How fast does the ATSB-36 preheat?
Atosa lists a 1 minute preheat time.
How many rack positions does the ATSB-36 have?
Four. The chrome broiler rack is removable.
Can I run each side of the ATSB-36 separately?
Yes. Dual valves run the left and right sides independently, so you can broil on one side and leave the other off.
Can the ATSB-36 mount on my range?
It ships with a range mount kit that fits Atosa 36" ranges only, such as the AGR-36G or AGR-4B36GR. Confirm the fit with us if you are not sure about your range.
Can the ATSB-36 mount on a wall?
Yes, with the optional Atosa wall mount kit 21208001048. At 143 lb, it needs a flat, solid wall that can hold its weight, per Atosa's installation overview.
What gas does the ATSB-36 use?
Atosa lists it for natural gas (5" W.C.) and propane (10" W.C.).
What certifications does the ATSB-36 have?
cETLus, ETL-Sanitation; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b.
What warranty comes with the ATSB-36?
1 year parts and labor (US only) on the ATSB-36.
Do I need a salamander or a cheese melter?
Choose the ATSB-36 salamander if you sear, broil or finish foods at different distances from the burners: it has a 4 position chrome rack and a 1 minute preheat. If you mainly melt cheese and brown toppings, the ATCM-36 has the same 43,000 BTU and weighs 48 lb less.
Where can I buy the Atosa ATSB-36 in Seattle?
Right here at Encore Seattle. The ATSB-36 is new and ships to your restaurant with free freight on orders over $500.
How fast can I get the ATSB-36 in Seattle?
We offer 1-3 day delivery from 12 distribution centers. Call or text +1 (206) 419-5801 to check timing for your address.
Spec Sheet and Manual
Download the Atosa ATSB-36 spec sheet (PDF, Rev. 08/24)
Download the Atosa ATSB-36 / ATCM-36 installation overview (PDF)
