Atosa ATFS-35ES-NG 16-Inch 35 lb ENERGY STAR Natural Gas Deep Fryer, 60,000 BTU, 3 Burners
See current pricing, availability and checkout for this item at The Restaurant Warehouse, our main store.
See Price & Buy at The Restaurant WarehouseThe Atosa ATFS-35ES-NG is a 15-3/5" wide floor model fryer for natural gas that holds 35 lb of oil. It has 3 burners with 60,000 BTU in total and holds 200°F to 400°F. It is ENERGY STAR certified.
At a Glance
- Size: 15-3/5" W x 30-1/10" D x 44-2/5" H
- Oil capacity: 35 lb
- Gas: natural gas, 3 burners, 60,000 BTU total
- Temperature: 200°F to 400°F, millivolt thermostat
- Baskets: two (2) nickel plated baskets with coated handles, basket hanger
- Mobility: four (4) casters standard
- Certifications: cETLus, ETL-Sanitation, ENERGY STAR
- Warranty: 1 year parts and labor
Most units ship within one business day from our warehouse with free freight and free lift gate to Seattle restaurants and the lower 48.
An ENERGY STAR Commercial Fryer
This ENERGY STAR commercial fryer runs on natural gas with three burners and 60,000 BTU in total. It holds up to 35 lb of oil and is 15-3/5" wide, the same size as the ATFS-40.
Is the ATFS-35ES-NG the Right Size for Your Line?
The ATFS-35ES-NG holds 35 lb of oil over 3 burners at 20,000 BTU each, 60,000 BTU in total. That works out to about 1,710 BTU per pound of oil. The 35ES is the ENERGY STAR model, with the lowest gas input in the line.
It is 15-3/5" wide, 30-1/10" deep and 44-2/5" tall, the same footprint as the ATFS-40 and ATFS-50, and weighs 133 lb.
Want more heat in the same space? The ATFS-40-NG holds 40 lb with 102,000 BTU, but it is not ENERGY STAR rated. Running on propane instead? The ATFS-35ES-LP has the same 60,000 BTU, with a 10" W.C. regulator instead of 4" W.C.
Good For
- Kitchens that want an ENERGY STAR fryer: the only ENERGY STAR model in the ATFS line
- Cafés and bars: fries and appetizers from 35 lb of oil
- A second fryer: a dedicated vat for one menu item
- Restaurants and diners: fries and fried sides
Built for Daily Commercial Use
- Stainless steel exterior and interior
- Welded stainless steel tank
- Heavy duty burners with a standing flame and standby pilots
- Millivolt thermostat that holds the temperature you set, from 200°F to 400°F
- Oil cooling zone in the bottom of the tank catches food bits and helps oil last longer
- Safety valve with an automatic voltage stabilizing function
- Self-reset high temperature limit
- Two (2) nickel plated baskets with coated handles and a basket hanger
- 3/4" NPT rear gas connection and regulator
- Four (4) casters standard
- ENERGY STAR certified
Pick the Right Fryer
| Model | Gas | Oil | Burners | Total BTU | Width |
|---|---|---|---|---|---|
| ATFS-35ES-NG (this model) | Natural gas | 35 lb | 3 | 60,000 | 15-3/5" |
| ATFS-35ES-LP | Propane | 35 lb | 3 | 60,000 | 15-3/5" |
| ATFS-40-NG | Natural gas | 40 lb | 3 | 102,000 | 15-3/5" |
| ATFS-40-LP | Propane | 40 lb | 3 | 90,000 | 15-3/5" |
| ATFS-50-NG | Natural gas | 50 lb | 4 | 136,000 | 15-3/5" |
| ATFS-50-LP | Propane | 50 lb | 4 | 120,000 | 15-3/5" |
| ATFS-75-NG | Natural gas | 75 lb | 5 | 170,000 | 21-1/10" |
| ATFS-75-LP | Propane | 75 lb | 5 | 150,000 | 21-1/10" |
Need propane? See the Atosa ATFS-35ES-LP, the same fryer for propane.
Optional accessories: fryer cover 21201001019, splash guard 21101001047, joiner strip 21101001046, mesh fryer screen R06018000069 and leg kit 301110006.
Shop all commercial deep fryers, including natural gas and ENERGY STAR models.
Buy the Atosa ATFS-35ES-NG in Seattle
Encore Seattle sells the Atosa ATFS-35ES-NG new, not used, with the full manufacturer warranty. If you are pricing a commercial fryer in Seattle, it ships with free freight to Seattle restaurants on orders over $500, and we offer 1-3 day delivery from 12 distribution centers. We deliver to kitchens in Pioneer Square, Wallingford, the U District and West Seattle, and to restaurants across the lower 48.
Compare more options in our Commercial Fryers Seattle collection, or call or text +1 (206) 419-5801 with questions.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Floor model natural gas deep fryer |
| Oil capacity | 35 lb |
| Gas type | Natural gas |
| Burners | 3, independent manual control |
| BTU per burner | 20,000 |
| Total BTU | 60,000 |
| Gas pressure (regulator) | 4" W.C. |
| Gas connection | 3/4" NPT, rear, with regulator |
| Temperature range | 200°F to 400°F |
| Thermostat | Millivolt |
| Safety | Self-reset high temperature limit; safety valve with automatic voltage stabilizing |
| Baskets | (2) nickel plated, coated handles |
| Basket size | 13-3/10" x 6-1/2" x 5-9/10" |
| Cooling zone | Yes, bottom of tank |
| Construction | Stainless steel exterior, interior and welded tank |
| Casters | (4) standard; leg kit 301110006 optional |
| Exterior dimensions | 15-3/5" W x 30-1/10" D x 44-2/5" H |
| Net weight | 133 lb |
| Shipping weight | 166 lb |
| Warranty | 1 year parts and labor |
| Certifications | cETLus, ETL-Sanitation, ENERGY STAR; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b |
Before You Order
- This is the natural gas model. Order the ATFS-35ES-LP for propane.
- Gas: 3/4" NPT rear connection with a regulator. Atosa sets it at 4" W.C. for natural gas.
- Check your space: the ATFS-35ES-NG is 15-3/5" wide, 30-1/10" deep and 44-2/5" tall, and weighs 133 lb.
Atosa ATFS-35ES-NG FAQ
What size is the Atosa ATFS-35ES-NG?
The ATFS-35ES-NG is 15-3/5" wide, 30-1/10" deep and 44-2/5" tall. It weighs 133 lb (166 lb shipping weight).
How much oil does the ATFS-35ES-NG hold?
35 lb.
How many BTU is the ATFS-35ES-NG?
60,000 BTU total: 3 burners at 20,000 BTU each, on natural gas.
What temperature range does the ATFS-35ES-NG have?
200°F to 400°F, with a millivolt thermostat that holds the temperature you set.
What gas connection does the ATFS-35ES-NG need?
A 3/4" NPT rear connection. It has a regulator set at 4" W.C. for natural gas.
Does the ATFS-35ES-NG come with baskets?
Yes. Two nickel plated baskets with coated handles, each 13-3/10" x 6-1/2" x 5-9/10", plus a basket hanger.
Does the ATFS-35ES-NG have legs or casters?
It comes with four casters, so the 133 lb fryer can be rolled out for cleaning. A leg kit (301110006) is optional.
What certifications does the ATFS-35ES-NG have?
cETLus, ETL-Sanitation and ENERGY STAR; conforms to NSF/ANSI 4 and ANSI Z83.11b; certified to CSA 1.8b. It is the only ENERGY STAR fryer in the ATFS line.
What warranty comes with the ATFS-35ES-NG?
1 year parts and labor. Genuine ATFS-35ES replacement parts are listed in the parts section on this page.
Should I choose the ATFS-35ES-NG or the ATFS-40-NG?
Choose the ATFS-35ES-NG if you want an ENERGY STAR fryer: it holds 35 lb of oil on 60,000 BTU. The ATFS-40-NG is the same 15-3/5" width with 5 lb more oil and 102,000 BTU, but it is not ENERGY STAR rated.
What is the difference between the ATFS-35ES-NG and the ATFS-35ES-LP?
Gas type and regulator. The ATFS-35ES-NG runs on natural gas with a 4" W.C. regulator; the ATFS-35ES-LP runs on propane at 10" W.C. Both are 60,000 BTU ENERGY STAR fryers with 35 lb of oil.
Where can I buy the Atosa ATFS-35ES-NG in Seattle?
Right here at Encore Seattle. The ATFS-35ES-NG is new and ships to your restaurant with free freight on orders over $500.
How fast can I get the ATFS-35ES-NG in Seattle?
We offer 1-3 day delivery from 12 distribution centers. Call or text +1 (206) 419-5801 to check timing for your address.
Spec Sheet
Download the Atosa ATFS-35ES-NG spec sheet (PDF, Rev. 07/25)
